Hansen Female Elbow
Hansen
$4.80
Size
Quantity
Hansen Easy True Fit Female Elbow
Fitting sizes 15mm to 50mm Maximum Working Pressure; 16 Bar (1600 kPa, 235 psi)
Fitting sizes 65mm Maximum Working Pressure; 12 Bar (1200 kPa, 174 psi)
Fitting sizes 80mm to 100mm Maximum Working Pressure; 10 Bar (1000 kPa, 145 psi)
Maximum working temperature 20°C
| Code | Size | Max Pressure at 20°C |
| HTE15 | 15mm | 16 Bar |
| HTE20 | 20mm | 16 Bar |
| HTE25 | 25mm | 16 Bar |
| HTE32 | 32mm | 16 Bar |
| HTE40 | 40mm | 16 Bar |
| HTE50 | 50mm | 16 Bar |
| HTE65 | 65mm | 12 Bar |
| HTE80 | 80mm | 10 Bar |
| HTE100 | 100mm | 10 Bar |
FEATURES & APPLICATIONS:
- Largest range of durable, high strength, commercial quality Threaded Pipe Fittings in the Southern Hemisphere
- Precision Heavy Duty Tapered Threads give a Strong Reliable Seal
- Manufactured from a Raw Material Approved For Use With Potable (drinkable) Water
- Manufactured from High Quality Glass Fibre Reinforced Nylon giving a Weather, Termite, Fungi & Bacteria Resistance
- Common Applications Include Horticultural, Agricultural, Irrigation, Marine & Plumbing
- Material strong enough to minimise potential cross threading
- WRAS - Approval for use with potable (drinkable) water as they will not leach contaminants into the water.
- Suitable for use above or below ground in varying operating pressures and temperatures
- Strong, Lightweight and Compact
- Available in a variety of thread combinations and connections.
- New Zealand Made
