APEX Pressure Reducing Valve 7.6 - FV7.6
$224.00
Quantity
APEX Pressure Reducing Valve 7.6 - FV7.6
Pressure compensated to give constant outlet pressure regardless of inlet pressure
Silicon rubber diaphragm and washer - no heat loop required
N.Z. forged, high quality, corrosion resistant DR brass body
Machined, assembled and 100% tested in N.Z.
One-piece forged brass fork with no water paths - no leaks!
Inlet: 15mm, 1/2" BSP (male) Outlet: 20mm, 3/4" BSP (male) Length: 138mm
Set pressures
FV7.6 - 65 kPa
Adjustable pressure range
FV7.6 - 15 to 100 kPa
Maximum Inlet Pressure: 2000 kPa
Maximum Inlet Temperature: Plastic Cap: 40°C
