Caroma Aire Dual Flush Toilet Cistern & Toilet Seat

Caroma Aire Dual Flush Toilet Cistern & Toilet Seat

An economy dual flush integrated plastic cistern and toilet seat with flush fitting connection plate, which conceals the flush pipe and water connection. Features a low profile lid design with chrome bezel and buttons.

Great product - Great price - Easy to install, good replacement option for the Caroma Trident Cisterns.

Includes Tasman wide seat - 390mm Wide x 495mm from the front to the back of the flap

Plastic, white only

Low level installation

Cistern Mechanism: The cistern incorporates a quiet inlet valve to reduce noise during the filling cycle. The dual flush outlet valve is operated by two clearly marked push buttons which offer the choice of half flush or full flush as required.

Inlet and Overflow: Inlet is in the RH position and is located on the underside of the cistern and is interchangeable. Overflow is internal as standard, external overflow kit available.

Connections: The Aire cistern must be used with an authorised matched 4.5/3 litre pan. The design allows for adjustment when coupled to a pan having the seat holes located between 200mm and 300mm from the wall. Recommended setout for an S-trap pan is 165mm from the centre of the S-trap to the finished wall.

Matched Pans: The following Caroma matched Smartflush 4.5/3 litre pans are recommended – Concorde Concealed and Trident.

Cistern is 418mm wide x 362mm high x 164mm deep
